Camera Copy Stands
Tabletop AutoColumn Copy Stand
RPS 1600 AutoColumn Copy Stand
It is designed with motorized AutoColumn technology to accomodate for efficient work with the iXG camera system and Capture One CH. The Phase One RPS 1600 features high precision camera positioning, and a geared movable camera arm. A camera leveling head secures precise and quick positioning. An LED baseboard insert is available for transparency scanning.
Floorstand AutoColumn Copy Stand
RPS 2300XL AutoColumn Copy Stand
It is designed with motorized AutoColumn technology to accomodate for efficient work with the iXG camera system and Capture One CH. The Phase One RPS 2300XL features high precision camera positioning, and a geared movable camera arm. A camera leveling head secures precise and quick positioning. An LED baseboard insert is available for transparency scanning.
Large Format AutoColumn Copy Stand
RPS 2300XXL AutoColumn Copy Stand
An AutoColumn copy stand capable of meeting the ever-increasing demand for fast, efficient large format digitization. For large, flat and thin objects such as maps, newspapers and drawings, the included metal cover board can be mounted onto the base, allowing for careful and secure positioning with magnets.
The copy stand utilizes a large, super-stable metal base. At 1300x1000mm, it supports objects larger than A0. Combined with the Phase One iXH 150MP, this means 300ppi can be easily and conveniently achieved while meeting the strictest FADGI, Metamorfoze and ISO 19264 digitization guidelines.
The new base comes with a set of heavy-duty, lockable castor wheels and an RPS-175 arm extension, providing accurate and stable camera positioning and support. A utility shelf underneath the baseboard provides a convenient solution for placing the controller box and other tools and accessories.
Column height
2.3m AutoColumn
Total height
3.1 m
Base Footprint
1300x1260mm
Baseboard
1300x1000mm
Utility shelf size
1300x545mm
Camera mounting plate
Arca Swiss type dovetail
Computer Interface
USB 2.0
Total Weight
180kg
Includes
RPS-175 camera arm extension (180mm)
Phase One 2-Motion
The RSP 2-Motion adds an adjustable, motorized 100 x 80 cm baseboard allowing for greater flexibility and use of different lenses when scanning larger objects. The baseboard can be fitted with a steel sheet plate up to DINA0 format for magnetic attachment of large drawings, maps etc.
Cradles
V-Twin Book Cradle
The Phase One V-Twin book digitization system combines the best imaging sensor technology with a robust, stable construction providing excellent ergonomics, safe material handling and an efficient workflow.
Maximum book size
A2+ (43x61cm)
Maximum book weight (Kg)
25
Maximum spine width (cm)
25
Imaging sensors
100MP CMOS, Back Side Illumination with Electronic Shutter
Image capture size & resolution
A2+ @ up to 460ppi
Color depth
RGB 16-bit or 14-bit per channel
Camera Interface
USB-C
Approvals
FCC Class A, CE, RoHS
LED Panels
CRI >98 at 100% brightness, >50,000 hrs durability
Desktop Book Cradle
The new Phase One Desktop Book Cradle is designed as a simple digitization cradle for small and medium size books and bound materials. Constructed from high-grade aluminum extrusions, its chassis provides a stable, reliable, and longlasting platform.
Maximum supported book size
A3 book page size (32cm x 42cm)
Maximum spine thickness (cm)
17 (option for 25)
Adjustable angle support
Yes
Adjustable base lifting
Yes, mechanical
Maximum opening angle (º)
130-140º
Glass platen size
A3 book page size (32cm x 42cm)
Glass fingers
4
Glass fingers size (cm)
2 x 8
Footprint (cm)
W50 x L60 x H45
Weight (kg)
15
Accessories & Lights
Phase One Film Capture Stage
The film capture stage provides an adjustable, geared support mechanism and is compatible with a range of carriers for glass plate negatives, and most popular film strip and sheet formats. It can be easily adjusted to position the object directly under the camera.
Phase One Film Carriers
The Phase One Film Carriers are designed to work with the Film Capture Stage, ensuring smooth handling and efficient workflow.
Supported film formats
35mm strips
120mm strips
9x12 cm
13x18 cm
18x24 cm
4x5 in
8x10 in
mounted 35mm slides
Phase One Glass Plate Holders
The Phase One Glass Plate Holders are designed to work with the Film Capture Stage, ensuring smooth handling and efficient workflow.
Supported glass plate formats
9x12 cm
13x18 cm
18x24 cm
24x30 cm
D8 R+ LED Light Pannels
The Phase One D8 R+ LED Panel is manufactured exclusively for Phase One by Akurat Lighting in Poland.
Featuring extremely high quality LEDs coupled with even diffusion, the D8 R+ LED Panel has a CRI value >98 at 100% brightness.
The D8 R+ LED Panel produces flicker free lighting suitable for any high end digitization project where even lighting and color accuracy are paramount.
- Flat LED panel with extremely even illumination
- Excellent color accuracy – CRI >98 at 100% brightness
- Flicker free – LEDs powered by direct current with no ripples
- Easy to handle, with angled yoke bracket for easy tilting of the panel
- Excellent diffusion
- Panel size 540x330mm
- Overall size 680x390mm
- Durability of LEDs – 50,000 hours
- Weight including AC adapter, yoke and mount – 5.5Kg
- Limited three year manufacturer warranty included
- Optional Accessory Kit includes barn doors and honeycomb grid
