Blue Ring XF Lenses

Blue Ring Lenses For XF Cameras

Exceptional image capture begins with outstanding optics

Medium format lenses from Phase One

Designed in Denmark

Danish design is known for functionalism, simplicity, and elegance. For over ten years, Phase One Denmark has led the design of the Phase One Camera System lenses, driving the finest engineering and manufacturing partners to create a higher standard of lens to support the creative ambitions of professional photographers.

German optics engineering

Schneider Kreuznach is a worldwide leader in optics and precision engineering. Building on a century of German optics expertise, the Schneider Kreuznach Blue Ring Lenses for the XF Camera are unmatched in quality, with a unique, individual, focus calibration for every Phase One XF lens.

Japanese high-tech manufacturing

The manufacturing home of our lenses is Japan, where our lenses are built by hand. Each lens is handled from start to finish by a single expert who oversees that every component is flawlessly assembled.

Watch how our lenses are manufactured in Japan

28mm LS f/4.5 Aspherical

The Schneider Kreuznach 28mm LS f/4.5 Aspherical provides full coverage of the 645 format and the market’s fastest flash synchronization capabilities – up to 1/1600s. The 28mm provides nearly distortion-free wide-angle coverage with minimal light falloff. It is the ideal lens for interior, landscape, architecture and creative editorial photography.

Angle of view

102.7º

Aperture range

f/4.5 - f/32

Focusing system

Autofocus | Manual

Minimum focusing distance

35cm | 1.15ft

Maximum magnification ratio

0.15x

Equivalent 35mm focal length

17mm

Filter

Sheet filter

Dimensions

90 x 136mm | 3.5 x 5.5in

Weight

1100g | 2.43lbs

SK_28mmLS_white_straight

35mm LS f/3.5

The Schneider Kreuznach 35mm LS f/3.5 is designed for tack sharp wide angle imaging of the 645 format and supports the market’s fastest flash synchronization capabilities – up to 1/1600s. This is a true architectural quality lens, challenged only by dedicated technical camera lenses. With minimum optical distortion and edge-to-edge sharpness, the 35mm is ideally suited to resolve the highest resolutions on the market.

Angle of view

89°

Aperture range

f/3.5 - f/32

Focusing system

Autofocus | Manual

Minimum focusing distance

0.5m | 1.64ft

Maximum magnification ratio

0.104x

Equivalent 35mm focal length

22mm

Filter

105mm

Dimensions

111mm x 119mm | 4.4in x 4.7in

Weight

1370g | 3.02lbs

SK-35mm_straight

45mm LS f/3.5

The Schneider Kreuznach 45mm LS f/3.5 lens provides a wide focal length that is perfect for almost any application, the Blue Ring 45mm f/3.5 offers edge-to-edge sharpness and nearly distortion free results. As with our other Blue Ring lenses, the 45mm supports flash synchronization up to 1/1600s.

Angle of view

74°

Aperture range

f/3.5 - f/32

Focusing system

Autofocus | Manual

Minimum focusing distance

55cm | 1.80ft

Maximum magnification ratio

0.116x

Equivalent 35mm focal length

28mm

Filter

95mm

Dimensions

101mm x 122.9mm | 4.0in x 4.8in

SK-45mm-LS-f3.5_straight

55mm LS f/2.8

The Schneider Kreuznach 55mm LS f/2.8 lens features minimal distortion on a semi-wide angle design, for a normal look. The 55mm is great for editorial portraits and on location lifestyle photography, and supports flash synchronization up to 1/1600s.

Angle of view

64°

Aperture range

f/2.8 - f/32

Focusing system

Autofocus | Manual

Minimum focusing distance

45cm | 1.47ft

Maximum magnification ratio

0.18x

Equivalent 35mm focal length

34mm

Filter

72mm

Dimensions

77.6mm x 86.5mm | 3.0in x 3.4in

Weight

660g | 1.3lbs

SK-55mm-LS_straight

80mm LS f/2.8

The Schneider Kreuznach 80mm LS f/2.8 lens is the standard focal length, offering the greatest versatility. A preferred choice for location fashion photographers using fill flash, the 80mm supports flash synchronization up to 1/1600s. The fast aperture allows for a shallow depth of field.

Angle of view

47°

Aperture range

f/2.8 - f/22

Focusing system

Autofocus | Manual

Minimum focusing distance

70cm | 2.3ft

Maximum magnification ratio

0.15x

Equivalent 35mm focal length

50mm

Filter

72mm

Dimensions

64.4mm x 86.5mm | 2.5in x 3.4in

Weight

500g | 1.1lbs

SK-80mm-LS_straight

80mm LS f/2.8 Mark II

The Schneider Kreuznach 80mm LS f/2.8 Mark II lens is the standard focal length, offering the greatest versatility. The natural field of view and distortion free aesthetic allows the photographer to focus on composition. Bright edge-to-edge sharpness, shallow depth of field, and sensational contrast always yield stunning results.

Angle of view

47°

Aperture range

f/2.8 - f/22

Focusing system

Autofocus | Manual

Minimum focusing distance

70cm | 2.3ft

Maximum magnification ratio

0.15x

Equivalent 35mm focal length

50mm

Filter

72mm

Dimensions

80.4 x 85.6 mm | 3.17 x 3.4 in

Weight

765g | 1.69lbs

SK-80mm-LS-MKII_straight

110mm LS f/2.8

The Schneider Kreuznach 110mm LS f/2.8 lens is a longer focal length with just enough optical compression for full-length fashion, beauty and portraiture. The 110mm is the preferred lens for location portraits utilizing shallow depth of field, thanks to the fast aperture and extreme anti-flare optical design.

Angle of view

29°

Aperture range

f/2.8 - f/22

Focusing system

Autofocus | Manual

Minimum focusing distance

90cm | 2.9ft

Maximum magnification ratio

0.16x

Equivalent 35mm focal length

68mm

Filter

72mm

Dimensions

83.3mm x 86.5mm | 3.2in x 3.4in

Weight

670g | 1.5lbs

SK-110mm_LS_straight

120mm LS f/4.0 Macro

The Schneider Kreuznach 120mm LS f/4.0 Macro lens is designed for the ultimate quality Macro 1:1 image, with a minimum focusing distance of just 37cm and beautiful bokeh. The 120mm Macro is ideal for close-up product shots, and equally ideal for close up beauty, action, nature and wildlife photography – making it the professional choice when you need to get as close as possible with your subject.

Angle of view

33°

Aperture range

f/4 - f/22

Focusing system

Autofocus | Manual

Minimum focusing distance

40cm | 1.3ft

Maximum magnification ratio

1.00x

Equivalent 35mm focal length

73mm

Filter

86mm

Dimensions

111mm x 83mm | 4.4in x 3.25in

Weight

1325g | 2.9lbs

SK-120 mm-LS_straight

150mm LS f/3.5

The Schneider Kreuznach 150mm LS f/3.5 lens is a standard portrait lens with applications in fashion, beauty, lifestyle and action. The 150mm features a long focal length and tack sharp results, in a compact and lightweight design.

Angle of view

26°

Aperture range

f/3.5 - f/32

Focusing system

Autofocus | Manual

Minimum focusing distance

150cm | 4.92ft

Maximum magnification ratio

0.12x

Equivalent 35mm focal length

93mm

Filter

72mm

Dimensions

87.1mm x 86.5mm | 3.4in x 3.4in

Weight

700g | 1.5lbs

SK-150mm-LS-f3.5_straight

150mm LS f/2.8 IF

The Schneider Kreuznach 150mm LS f/2.8 IF lens is our fastest telephoto lens, providing razor thin depth of field at f/2.8, and beautiful out-of-focus bokeh. The 150mm IF is the perfect lens for studio and location portraiture alike.

Angle of view

25°

Aperture range

f/2.8 - f/22

Focusing system

Autofocus | Manual

Minimum focusing distance

1.0m | 3.28ft

Maximum magnification ratio

0.192x

Equivalent 35mm focal length

96mm

Filter

95mm

Dimensions

115mm x 141.6mm | 4.5in x 5.6in

Weight

1658g | 3.65lbs

SK-150mm-LS-f2.8_straight

240mm LS f/4.5 IF

The Schneider Kreuznach 240mm LS f/4.5 IF is an ideal lens for you to get close to your subjects whether you’re shooting beauty, sports, landscape or wildlife. The 240mm provides exceptional performance and high resolving power, for super sharp results. For maximum focal length and compression, the 240mm lens is compatible with the 2x Converter.

Angle of view

16.5°

Aperture range

f/4.5 - f/22

Focusing system

Autofocus | Manual

Minimum focusing distance

170cm | 5.58ft

Maximum magnification ratio

0.17x

Equivalent 35mm focal length

149mm

Filter

86mm

Dimensions

169mm x 104.5mm | 6.7in x 4.1in

Weight

1600g | 3.53lbs

SK-240mm_straight

40-80mm LS f/4.0-5.6

The Schneider Kreuznach 40-80mm LS f/4.0-5.6 zoom lens delivers prime lens quality across the full focal range, for ultra sharp images. The 40-80mm lens has practically no focus shift and offers a zoom lock on the barrel. When partnered with the Schneider Kreuznach 75-150mm LS f/4.0-5.6 zoom lens, you have coverage of a complete focal length range from 40mm to 150mm with just two lenses.

Angle of view

W 82° | T 47°

Aperture range

W f/4 - f/32 | T f/5.6 - f/45

Focusing system

Autofocus | Manual

Minimum focusing distance

60cm | 1.97ft

Maximum magnification ratio

W 0.094x | T 0.179x

Equivalent 35mm focal length

W 25mm | T 50mm

Filter

105mm

Dimensions

150mm x 111mm | 5.9in x 4.4in

Weight

1800g | 4.0lbs

SK-40-80mm-straight

75-150mm LS f/4.0-5.6

The Schneider Kreuznach 75-150mm LS f/4.0-5.6 zoom lens is the most versatile normal to tele lens for the XF Camera System, providing prime lens quality across a convenient focal length range. The 75-150mm lens has practically no focus shift and offers a zoom lock on the barrel. When partnered with the Schneider Kreuznach 40-80mm LS f/4.0-5.6 zoom lens, you have coverage of a complete focal length range from 40mm to 150mm with just two lenses.

Angle of view

W 50° | T 26°

Aperture range

W f/4 - f/22 | T f/5.6 - f/45

Focusing system

Autofocus | Manual

Minimum focusing distance

100cm | 3.28ft

Maximum magnification ratio

W 0.09x | T 0.164x

Equivalent 35mm focal length

W 47mm | T 93mm

Filter

95mm

Dimensions

172mm x 105.5mm | 6.8in x 4.2 in

Weight

1800g | 3.96lbs

SK-75-150mm_Straight

2x Teleconverter f/2.0

The 2x Teleconverter f/2.0 offers photographers great optical compression that effectively eliminates the distance between objects in the captured scene. This is a great effect for shooting stunning landscapes and forced perspective. The 2x Teleconverter is compatible exclusively with the Schneider Kreuznach 240mm LS and 150mm LS lenses, as well as the Phase One 150mm AF lens, and effectively doubles the focal length of these lenses to 480mm and 300mm respectively.

Compatibility

150mm LS | 150mm LS IF | 240mm LS IF | 150mm AF

SK_telecon_straight
